The Kite

All controls are stereo except O/P TRIM and are indented for easy recall;'

HPF (High Pass Filter) operates at 20 & 40Hz with a 12dB/octave curve;

BASS BOOST and BASS CUT both have 2 selectable operating frequencies,
which can be used together for a Mid Cut effect;

TOP SHELF is a broad Mid/Top Lift, a little like a Presence control. Also has 2 frequencies.

AIR boosts the higher Top and will give an amazing clear yet warm sound, only available with out valve products;

ATTITUDE is our own switch that adds those special 2nd harmonics only possible with valves! ;

OUTPUT TRIM - Separate controls to adjust finely the 2 channels, also -6dB switches;

XLR connectors, "semi floating" inputs and unbalanced outputs are employed;

A transformer balanced version is available to order, in Purple.
