JZ Microphones BT 201/3s (Stereo)
| Price ex. VAT |
683 EUR |
|---|---|
| Price incl. 21% VAT |
826 EUR |
BT201|3s is a matched pair of BT201|3 series microphones, offering choice of 3 capsules that satisfy the demands of all common studio and live applications - cardioid, open cardioid and open cardioid -20db option capsules. Matched pair is available to provide balanced stereo recordings. Also optional accessories JZI|7 and JZ|HLDR are recommended for BT201 series microphones.
Michael Wagener (Metallica, Queen, Ozzy Ozbourne, Alice Cooper)
"I tried the combination of a BT201 and BT301 on acoustic guitar and it was the best sound I’ve heard from any new microphone."
Steve Orchard (Air Studios - U2, Travis, Paul McCartney)
"When I was getting the acoustic guitar sound for Porcupine Tree’s newalbum I set up a pair of excellent c12’s & also set up the BT201 & the Black Hole in a stereo configuration. When comparing the 2 sets of mic’s the JZ mic’s were by far the best sounding crisp & present, I was amazed!"
Transducer type: electrostatic
Operating principal: pressure gradient
Diaphragms active diameter: 13 mm
Frequency range: 20 Hz to 20 kHz
Polar pattern: Cardioid, open cardioid, open cardioid -20dB
Output impedance: 50 ohms
Rated load impedance: 1000 ohms
Suggested load impedance: >250 ohms
Sensitivity at 1000 Hz into 1000 ohms load: 11 mV/Pa
S/N Ratio CCIR 468-3 weighted: 71 dB
S/N Ratio DIN/IEC 651 A-weighted: 82 db-A
Equivalent noise level DIN/IEC A-weighted: 12 dB-A
Maximum SPL for 0.5% THD at 1000 ohm load: 140 dB
Dynamic range of the microphone preamplifier: 128 db
Phantom powering voltage on pins 2 & 3 of XLR: +48 V (+/-4 V)
Current consumption: < 2 mA
Output connector: 3-pin XLR male, gold plated contacts
Signal polarity: positive toward pressure on a diaphragm produces positive polarity voltage on XLR pin #2relatively to pin #3
Dimensions: 161,5 mm lenght x 24 mm diameter
Weight: together with magneticly attached head, 140 g
