Your favorite D/A converter may not be the latest but you like its sound, appearance and features. So you don\'t want to buy another expensive DAC just to connect a computer. This is where our interfaces come in. The INT202 / INT203 allow any DAC to be connected to a FireWire or Thunderbolt ported computer. This is done, optimally, by slaving to the computer\'s internally generated clock with absolute bit transparency.
DIGITAL INPUTS
DIGITAL OUTPUTS
SYNCHRONIZATION
- Two Firewire 400 connectors (also serve as output with the INT203).
- RCA connector (INT203 only).
- XLR connector (INT203 only).
DIGITAL OUTPUTS
- Two RCA connectors (INT203 only one).
- Two XLR connectors (INT203 only one).
- Word-length up to 24 bits
SYNCHRONIZATION
- Sampling frequency is generated internally.
- INT203: Synchronization can be supplied via the RCA or XLR inputs.
- Supported sampling frequencies: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, and 192 kHz
DSP ALGORITHMS
- Volume control.
- Absolute polarity control.
- Bit transparency checking.
DIMENSIONS
INT202 and INT203
- Depth: 10.5 cm / 4.13 inches
- Width: 10.5 cm / 4.13 inches
- Height: 4.4 cm / 1.73 inches
- Height with feet: 4.7 cm / 1.85 inches
IR Remote Control (optional purchase)
- Depth: 2.1 cm / 0.83 inches
- Width: 4.5 cm / 1.78 inches
- Height: 16.6 cm / 6.53 inches
