Lyra represents the pinnacle of compact audio interfaces. Packing Prism Sounds trusted, uncompromising AD/DA conversion into a compact chassis perfect for use in the studio or on the road. Based on the Orpheus’ audio path and clock circuitry, Lyra is ideal for those who don’t require a large I/O count, but do demand the highest quality and most transparent AD/DA available.
RENOWNED AD/DA CONVERSION
Lyra cuts no corners in its design and boasts the same trusted Prism Sound convertors used on countless hit records. It’s ultra-transparent characteristic means what you put into the Lyra is exactly what you get out of it.
PRISTINE PRE-AMPLIFICATION
Featuring a single class-A microphone preamp, Lyra 1 guarantees superbly clean, detailed recordings that capture a performance the way it was intended.
SOFT-CLIP LIMITING (OVERKILLER)
Lyra’s analogue input channels include a switchable Prism Sound \\\\\\\'Overkiller\\\\\\\' circuit. This soft-clip limiter gently absorbs transients and allows signal levels to be pushed to their limits without risk.
QUALITY SUPPORT
Prism Sound\\\\\\\'s reputation for audio excellence has been matched only by its top quality after-sales support and technical advice. The longevity of a Prism Sound product is a testament to the dedicated team behind it.
- No-compromise, full Prism Sound audio quality
- Class compliant (UAC2) USB interface
- ASIO and WDM drivers for Windows (32 and 64bit)
- Native CORE AUDIO on Mac OS X
- UAC2 operation on Linux (no control panel support)
- Ethernet interface with low-latency AVB capability
- Two Prism Sound premium-quality AD channels
- Two high-end integrated microphone preamps (typ. -130dBu EIN)
- Microphone inputs have switchable phantom power and 20dB pads
- MS matrix on microphone inputs
- Two high-impedance front panel instrument inputs
- Prism Sound “Overkillers” to gracefully control transient overloads
- Four Prism Sound premium-quality DA channels, plus independent stereo headphone DA
- Outputs selectable between workstation bus or Lyra mixer
- New high-drive headphone output with front-panel volume control
