Ribbon microphone
Any audio equipment that succeeds in imitating human hearing has always had a permanent place in the toolbox of audio engineers; Early microphones, ribbon microphones, are such devices. It has a natural human-like way of hearing sounds and, therefore, outperforms other types of microphones.
Nothing comes for free though; the ribbon microphone, as with the human ear, is a delicate and fragile instrument that is unable to withstand long periods of time in front of a loud sound source without risking permanent damage.
Sandhill has solved this "fragile" ribbon microphone limitation, while still preserving the classic ribbon tone and behavior. Sandhill ribbon microphones are constructed by applying modern materials and fabrication methods to the traditional and well proven concept, resulting in more sound definition, musicality, durability, and convenience than previously seen with ribbon microphones.
The mechanical structure consists of rigid precision machined aluminum and steel parts, resulting a resonance free structure for the ribbon.
The ribbon element is an electrically conductive composite material, making it significantly stronger than traditional aluminum ribbons. This extra strength allows Sandhill to use only minimal screening around the ribbon without the fear of broken transducers. The microphone can handle unbelievably high sound pressure levels without any sign of distortion or physical damage. The Sandhill unique custom corrugated ribbon profile is designed to minimize the effect of standing wave modes on a ribbon element.
Finnish technology, design, and manufacturing, with the addition of Swedish Lundahl Transformers means 100% European made.
The active circuitry of the Sandhill microphone is designed to prevent the preamplifier from damping the ribbon. The circuit works as a very high constant load for the ribbon, while providing a low output impedance that any preamp can handle. With active electronics, the ever critical transient response and low end frequency response are optimized. Using passive ribbon microphones with preamps that have a low input impedance is a gamble, but the Sandhill mics will work optimal with any preamp capable of delivering nominal gain and 48 Volt phantom power.
Directional characteristics: Figure-of-Eight
Ribbon dimensions: 60 × 4,7 mm
Ribbon technology: NCRT (Nano Composite Ribbon Technology)
Ribbon profile: Sandhill VariGeo (Variable Geometry)
Principle of operation: Pressure Gradient
Body type: Machined Aluminium
Frequency range: 20 Hz - 15 kHz
Sensitivity (open circuit): 3,5 mV/Pa *
Equivalent noise level (A-weighted): 22 dB ( IEC 651) *
Equivalent noise level (CCIR-weighted): 36 dB (ITU-R BS.468-4) *
S/N ratio, re. 1 kHz at 1 Pa (94 dB SPL) A-weighted: 72 dB*
Max. SPL, peak before clipping: 154dB
Output impedance: 105 ohm, impedance balanced
Current consumption: 3,1mA, 48 volt phantom powered
Connector: 3-pin male XLR connector, pin 2 Hot
Weight: 450 g
Dimensions: 50/172/25 mm
* exact value is available in the microphone's individual measuring data
